New IceBear Spartan-8 (PAH125-8E) -125CC Fully Auto Youth ATV with Reverse - 8 inch Wheels
IceBear Spartan-8 125 ATV, Fully Auto with Reverse, 8 inch Wheels
Color Options: Red, Blue, Black, Green Camo, Desert Camo, Yellow, Black spider, Red SpiderHeight Recommendation: 4ft-5ft tall Rider
| Engine | 125cc, 157FMI, Kangdi |
| Transmission | Fully automatic with Reverse |
| Drive type | Chain |
| Belt and/or chain size | Chain: 420H 100L |
| Starter System | Elec start |
| Fuel system | Gasoline, 0.53gal, carburator |
| Brakes (Front/Rear) | Drum/Disk |
| Tire size(Front/Rear) | 19x7-8 ; 18x 9.5-8 |
| Wheel size and type(Front/Rear) | 8, Steel |
| Oil capacity and type (in liters) | 0.8L, Air cooled motorcycle oil with clutch additive |
| Gear oil type and capacity( in liters) | N/A |
| Battery | 12V/5Ah |
| Lights | Headlight is Led, taillight is standard, no turn lights |
| Suspension(Front/Rear) | Double a-arm suspension / Single arm suspension |
| Dimensions(in inches) | Assembled(LxWxH): 59.8x37x36.2, Crated(LxWxH): 51.6x31.1x26.8, Seat height: 26-3/8", Wheelbase: 37.8 |
| Weight | 325 lbs |
| Weight capacity | 198 lbs |
| Ground clearance (in inches) | 3.5 |
| Assembly required | Wheels handlebars, front rear racks, battery |
| Special features | Remote kill key fob, throttle limiter |
| EPA approved | Yes/No |
